High-Precision MT-FA Fiber Array (V-Groove)

FEATURE :

Ultra-Precise Pitch Tolerance

Channel pitch tolerance within ±0.5 µm, ensuring superior multi-channel optical alignment & low coupling loss.

Ultra-Low Insertion Loss

Optimized 45°/0° polishing process delivering typical IL ≤ 0.35dB  and Return Loss ≥ 50 dB.

Low-Stress Reliability

Built with low-stress, high-temp epoxy for zero optical drift from -40°C to +85°C.

Ultra-Compact Design

Micro V-groove substrate structure perfectly tailored for Silicon Photonics (SiPh), AWG, and CPO packaging.
